Lathe Machines

Specifications

Lathe Machines

For seven years, industrial machinery corporation has been the largest Lathe Machines manufacturer in India. We have been engaged in manufacturing and supplying of lathe machines since 2011 when our company came into being. Through working for more than 7 years we have gained all the needed expertise to produce world-class lathe machines. We use all the technical knowledge we have along with the latest technologies available in the market to manufacture our lathe machines. For making our lathe machine, we use only the raw material that is coming from the most natural resources and which has been approved by our quality control team for use. Our quality control team double checks every piece very thoroughly for any sort of flaw or defect and any piece found with even a slightest of flaw is immediately abandoned from use. This strictness that we show in our work allows us to make every machine of ours, a masterpiece. We have a whole list of buyers from various countries across the world who buys lathe machines from us and have given us the tag of being the best lathe machines company in the world. Our lathe machine has an 8-speed gearbox and toughened gears which makes the performance of our machine a far stronger and brawny than others. There are few variants of lathe machine that we manufacture here at our Ludhiana based manufacturing unit. Let’s have a look.

Light Duty Lathe Machine-this machine as suggested by its name is perfect for forming and de-forming objects on small scales. This machine is perfect for working with small level work-shops and tool-rooms. We have designed this variety of lath machine to be extremely accurate and user-friendly. The programming of this machine allows the user to create lathes with extreme precision and accuracy. Since it is a light duty lathe machine, the controls of this machine are very easy to learn.

Medium Duty Lathe Machine: this lathe machine is designed to perform lathes in medium-sized factories and workshops. This size of lathe machine is best for performing their tasks in power plants, steel rolling mills, workshops, paper mills and tool rooms. We design our lathe machines exactly as per the requirements of our clients to give maximum ease while performing. \n \nHeavy duty lathe machine: heavy duty lathe machine is used to perform heavy duty tasks of producing strong and robust industrial designs. The design of this machine has been created in such a way that it can comfortably work long hours with showing any signs of break-down. This heavy-duty lath machine is specially designed and built to perform heavy duty metal and woods tasks. This is a state-of-an-art machine made using all the latest technologies to give high-quality results every time it is switched on.

Extra heavy duty lathe machine: this extra heavy duty lathe machine is used with the purpose of the shaping of de-shaping very hard materials to perform this task; extra heavy duty lathe machine has been designed and manufactured with extra tough raw material to give it extra endurance.

Roll turning lathe machine: this roll turning lathe machine has created to make cylindrical rolls and is a perfect machine for this purpose. This machine has been made extra tough and with extra endurance to provide full strength while the operator is working on it. This machine works best in business entities like power plants, steel rolling mills, and heavy workshops and industries to accomplish this task of roll turning.

Standard Accessories

• Face Plate


• Motor Plate


• Steady Rest


• Follow Rest


• Full Norton / Semi Norton Gear Box


• Gear Set

Optional Accessories

• Dog Chuck


• True Chuck


• Electric Motor,


• R/F Starter

 Specifications:

Model	BL - 4.5'	BL - 6'	BL - 8'	BL - 10'	BL - 12'
Length of Bed	4.5'	6'	8'	10'	12'
Width of Bed	300	350	400	450	500
Height of Centre	250	300	350	400	450
Swing Over Bed	500	600	700	800	900
Swing in Gap	700	800	950	1150	1300
Swing Over Saddle	325	375	450	500	550
Admit Between Centre	600	900	1300	1800	2250
Spindle Hollow	40	75	90	100	100
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

• Face Plate


• Motor Plate


• Steady Rest


• Follow Rest


• Full Norton / Semi Norton Gear Box


• Gear Set
• R/F Starter

Optional Accessories

• Dog Chuck


• True Chuck


• Electric Motor, Pully

 Specialization

• Semi Gear Head Model (Belt


• Hardened Bed for Long Life (Optional)


• More Accurate


• Extra Feed Shaft

 Specifications:

Model	BL - 4.5'	BL - 6'	BL - 8'	BL - 10'	BL - 12'
Length of Bed	4.5'	6'	8'	10'	12'
Width of Bed	300	350	400	450	500
Height of Centre	250	300	350	400	450
Swing Over Bed	500	600	700	800	900
Swing in Gap	700	800	950	1150	1300
Swing Over Saddle	325	375	450	500	550
Admit Between Centre	600	900	1300	1800	2250
Spindle Hollow	40	75	90	100	100
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

• Face Plate


• Motor Plate


• Steady Rest


• Follow Rest


• Full Norton / Semi Norton Gear Box


• Gear Set


• R/F Starter

Optional Accessories

• Dog Chuck


• Motor Pully


• Electric Motor


• R/F Starter

 Specifications:

Model	LB - 10'	LB - 12'	LB - 14'	LB -18'	LB -20'
Length of Bed	10'	12'	14'	18'	20'
Width of Bed	500	500	550	600	650
Height of Centre	450	450	500	550	550
Swing Over Bed	875	875	975	1050	1050
Swing in Gap	1300	1300	1400	1550	1550
Swing Over Saddle	550	550	600	650	650
Admit Between Centre	1800	2250	2700	3600	4050
Spindle Hollow	90	104	104	104	104
Power Required	3 H.P.	5 H.P.	7.5 H.P.	10 H.P.	10 H.P.
Lead Screw Pitch	2	2	2	2	2
Spindle Speed	6	6	6	6	6

Standard Accessories

• Face Plate


• Motor Plate


• Steady Rest


• Follow Rest


• Full Norton / Semi Norton Gear Box


• Gear Set


• R/F Starter

 Optional Accessories

• Dog Chuck


• Motor Pully


• Electric Motor, Pully.

 Specifications:

Model	LBL - 4.5'	LBL - 6'
Length of Bed	4'6"	6'
Width of Bed	250	250
Height of Centre	200	200
Swing Over Bed	390	390
Swing Hollow	42	42
Admit Between Centre	500	1000
No. of Spindle Speeds	8	8
Range of Spindle Speeds	50 - 1200	50 - 1200
No. of Feeds	32	32
Range of T.P.I. Thread	4 -- 56	4 -- 56
T.P.I. of Lead Screw	4	4
Power Requirement	2 H.P.	2 H.P.

Standard Accessories

• Face Plate


• Motor Plate


• Steady Rest


• Follow Rest


• Gear Set


• R/F Starter

Optional Accessories

• Dog Chuck


• Motor Pully


• Electric Motor, Pully.


• Full Norton Gear Box


• Extra Feed Shaft

Specialization

• Hardened Bed for Long Life (Optional)


• More Accurate
•

 Specifications:

Model	LL- 4.5'	LL - 6'	LL - 7'	LL - 9'	LL -10'	LL - 12'
Length of Bed	4.5'	6'	7'	9'	10'	12'
Width of Bed	300	300	320	320	395	395
Height of Centre	225	225	250	250	375	375
Swing Over Bed	425	425	475	475	725	725
Swing in Gap	550	550	600	600	850	850
Swing Over Saddle	225	225	300	300	275	275
Admit Between Centre	500	950	975	1575	1875	2450
Spindle Hollow	53	53	53	53	78	78
Power Required	1 H.P.	2 H.P.	2 H.P.	3 H.P.	3 H.P.	5 H.P.
Lead Screw Pitch	4	4	4	4	4	4
Spindle Speed	8	8	8	8	8	8
